High Capacity inverter

Range: 5 VA to 100 KV Offline

Payal Power Systems DSP Sine Wave Inverter - High frequency Series, with reliable, regulated and stabilized Pure Sine Wave Output, is a new milestone towards complete power generation system that is suitable for running household appliances.

Its high frequency operation results in lesser hardware and reduced weight gives it a sleek look.

Payal Power Systems DSP Sine Wave Inverter - High frequency series supplies pure power, is 100% safe to run most sophisticated, expensive equipment without the irritating humming sound. The inverter consists of DC-DC converter which converts the battery voltage to higher voltage, and it has H - Bridge inverter which is fully governed by a powerful microcontroller. The output of this inverter is finally filtered to pure sine wave using tuned LC filters. The inverter is capable of completely eliminating the traditionally bulky 50Hz transformer. The battery charger comprises an SMPS based topology which gives pure DC current to the battery and hence enhances the battery life and reliability. The battery terminals are completely isolated from the output and hence it is relatively safe. Based on triple conversion technology he batteries are safe from surges produced from the compressive loads.

Payal Power Systems sine wave inverter ensures

  • Full safety of highly sophisticated equipment.
  • 100% Pure, reliable and regulated Power.
  • Low running cost.
  • Extended power backup time.
  • Easy maintenance.
  • No humming noise from any load.
  • Great power saving.
